Titan PowrCoat™ 940 Air Powered Spray

0533940C

  • Sale
  • Regular price $4,195.00
Free Shipping!

Checkout Secure

PowrCoat™ 940 Air Powered Spray

POWRCOAT™ sprayers are great for virtually any application, including architectural, finishing, industrial maintenace, corrosion control, cold applied roofing, waterproofing, and marine protective coatings.

Spray Features

  • Severe Service: Hard-chrome polished piston and cylinders give long life.
  • Tungsten carbide valve seats with hardened steel check balls provide better performance and durability.
  • PowrCoat™ piston is engineered to provide unmatched chemical and solvent resistance while creating an ultra-smooth surface that operates with a smooth stroke that provides less friction and wear.
  • Pumps are designed for easy application of today’s low-VOC, high solids, and abrasive coatings.
  • Aircare System: Complete FRL (Filter, Regulator, Lubricator) standard with every PowrCoat. Eliminates motor icing.
  • Automatic draining moisture trap. Easy access air filter & lubrication reservoir.
  • Anti-icing motor ensures continuous operation
  • Proven spool valve design with only five moving parts
  • High efficiency air motor
  • Long-life packings Severe Service™ pump
  • Large 16” pneumatic wheels
  • Integrated wall mount bracket
  • Heavy duty cart
  • Hose wrap and gun holder
  • Heavy duty crane hook
  • Lubrication adjustment for versatile use
  • High capacity outlet filter reduces tip plugging
  • Lift handles

Spray Specifications

  • Air Motor Diameter: 9
  • Ratio: 40:1
  • Stroke Length: 4.0
  • Max Operation Pressure: 4000 PSI
  • Max Air Input Pressure: 100 PSI
  • Max Recommended Air Volume Requirements: 116 CFM
  • Fluid Output Recycle: 182 CC
  • Max Recommended Output: 4.0 GPM

Click Here To Download The PowrCoat™ 940 User Manual
